How To Build A BBQ Grilling Station

Watch the Video
Print Project Instructions
Tools & Materials
Project Estimating
Grill Dimensions

Grill out more often with an attractive and functional BBQ Grilling Station. Learn here just how easy it is to build. This project demonstrates how to build on a hard,level surface, such as concrete or pavers. To build on soil, you must create a foundation pad.

Step 1: Build the First Post/Pillar

Mark out the location of your grilling station. Draw an 87 in. (2.2 m) minimum guideline where the back of the BBQ grilling station will be constructed.

Place the first Corner Block on the guideline where you want to begin. Then place 3 more Corner blocks and 2 AB York blocks

post1course1

Use a square to line up the blocks to ensure your post/pillar is square. Remove the raised ring on one of the AB York Blocks using a hammer and chisel. This will provide a flat surface for the next course of blocks. On the second course, place 4 Corner blocks so that they offset the blocks beneath them. Split an AB Dublin end-split block and place the large piece with the raised rings facing down and the split side against the Corner block (Figure 2). Save the smaller piece to be used at the end of the wall panel.

post1course2

Step 2: Build the Wall Panel

Begin the wall panel by installing the first 2 courses at the same time, using the patterns shown (Figure 3), or one you have chosen. In this example we are alternating between AB Dublin and AB York blocks. Building the first 2 courses at the same time will ensure that the blocks line up properly. End the base course of the wall panel with a Corner block. End the second course of the wall panel with the remaining small piece of the AB Dublin end-split block used on the post/pillar(Figure 3).

Courses2ndpostshaded

Step 3: Build the Second Post/Pillar

Continue building the second post/pillar by placing 3 additional Corner Blocks and 1 AB York block as shown (Figure 4).

post2course1

Use a square to position the blocks. Remove the raised ring on the AB York block with a hammer and chisel. Build the second course of the post/pillar by placing 4 Corner blocks starting with the first Corner block against the small piece of the AB Dublin end-split block (Figure 5).

post2course2

Step 4: Continue Building

Continue stacking courses by repeating Steps 1-3 until the desired height is achieved. This example uses a total of 5 courses, plus one additional course of 5 Corner blocks to each post/pillar. The wall panel is one course lower than the posts/pillars to allow for movement of the grill hood (Figure 6).

GrillSideViewOpen60102

Step 5: Finishing the BBQ Grilling Station

Place Wall Caps on top of the wall panel by alternating the caps to keep a straight line. Secure the caps in place with masonry adhesive (adhesive optional). Choose a countertop material to fit your design(Figure 7). Set your countertops in place and check for level. Shims may be used if adjustments are necessary. Secure the countertops in place with masonry adhesive, (adhesive optional) move the grill into place and you are ready to fire up the grill!

GrillN60104

Materials Needed:

  • 39 in(0.99 m) Grill
  • 50 Corner Blocks
  • 21 AB York Blocks
  • 12 AB Dublin Blocks
  • 5 Wall Caps
  • 2 Outdoor Countertops
  • 24 in x 32 in (600 mm x 800 mm)
  • 2 Tubes of Masonry Adhesive

Tools Needed:

  • Square
  • Measuring Tape
  • String Line
  • Level
  • Hammer & Chisel
  • Safety Glasses & Work Gloves

The dimensions of this BBQ grilling station used in this example are 36 in. H x 36 in. D x 87 in. W (0.9 m H x 0.9 m D x 2.2 m W) using a 39 in. (1.0 m) wide grill. To build using a different size grill, see(Figure 8) for information on other grill widths.

Figure 8: Block Counts for Common Grill Widths*

Block Type30 in.
(762 mm)
39 in.
(0.99 m)
48 in.
(1.2 m)
AB York262126
AB Dublin71212
Wall Caps456
Corner Blocks505050
